“Addition of a Mixing Valve” During the last 6 weeks, the R. L. Deppmann Monday Morning Minutes concentrated on re-circulation systems where the supply temperature to the system was the same as the outlet temperature of the water heater. Today we will examine the addition of a Lawler master mixing valve in the system.
High Rise Considerations The last article, part 5, showed an example of a high rise system with pressure reducing valves (PRVS) and the importance of the correct setting of the balance valves. The example we used showed balance valves with as much as 18 PSIG across them at a low flow. When a design starts to incorporate
High Rise Considerations The last article, Part 4, showed an example of a high-rise system with pressure reducing valves (PRV’s) and their effect on the …
The last three articles outlined pump selection in domestic water recirculation systems. In general, these systems have low flow and low head pumps. What happens in a high rise with pressure reducing valves (PRV) in the hot water supply? The pressure reducing valve introduces a fixed pressure drop which must be added to the calculations.
The purpose of the domestic water recirculation system is to delivery hot water near a fixture during times when there is no draw. If someone is using hot water in the next room or apartment or process; the hot water is near enough to your fixture so the hot water is delivered in seconds, not minutes.
Let’s assume the domestic hot water supply is a total length of 1000 ft. That is the entire pipe on all of the floors. Let’s also assume an average of 15 BTU/hr/ft of loss through the supply pipe insulation. Now let’s assume the recirc piping is 300 ft total at an average of 10 BTU/hr/ft of loss. What flow rate is required for a 10 degree ΔT? What flow rate is required for a 5 ΔT?
The R. L. Deppmann Monday Morning Minutes series will focus on the plumbing portion of the new construction and building facility business for the next few months. The topics will be domestic water recirculating systems, pressure booster systems, volume and instantaneous water heaters, and mixing valves. I’ve had 6 job site visits in the last 2 months to help engineers, service contractors, and facility managers solve problems with domestic water recirculating systems. It seems this is a good place to start.
Centrifugal pumps find open cooling tower applications are the toughest duty there is in hydronic cooling systems. Pumps do best with piping systems that provide …
System curves give insight into energy analysis, pump operation, and control setting analysis. Unlike closed hydronic systems, open systems rarely have a system curve that …
There are times when a little more capacity or a little more safety factor is needed from a pump selection. Often, we are asked about …
